/ F2 Pro
industrial FDM/FFF 3D printer
for large-scale and non-standard items
- UNLIMITED OPPORTUNITIES
- INDUSTRIAL FDM/FFF PRINTER
for large-scale and non-standard items
- UNLIMITED OPPORTUNITIES
- INDUSTRIAL FDM/FFF PRINTER
/ F2 Pro
industrial FDM/FFF 3D printer
for large-scale and non-standard items
F2 Pro broadens the horizons for FDM 3D printing technology.
It is faster, smarter, more powerful and truly larger.
It is faster, smarter, more powerful and truly larger.
F2Pro # nbsp; - an industrial 3D printer, ideal for printing large and # nbsp; non-standard products (print area 1000*600*1000 mm).
Two independent high-temperature extruders (up to 550°C) support printing with not only standard polymers (ABS, PLA, PP, etc.) and engineering polymers (ASA, PC, ABS + CF, etc.), but also with high-temperature polymers such as PEEK , PEKK, Ultem, PEEK + CF, etc.
Two independent high-temperature extruders (up to 550°C) support printing with not only standard polymers (ABS, PLA, PP, etc.) and engineering polymers (ASA, PC, ABS + CF, etc.), but also with high-temperature polymers such as PEEK , PEKK, Ultem, PEEK + CF, etc.
The F2 printing technology provides an ultra-fast heating of the extruder to the operating temperature in just 3 seconds, the accuracy of maintaining the melt temperature up to 0.3°C, and the system of quick changing cartridges with nozzles of different diameters makes the printing process simple and fast.
independent heated (up to 70°C) cells for two coils weighing
up to 5 kg are installed in printer.
independent heated (up to 70°C) cells for two coils weighing
up to 5 kg are installed in printer.
Diameter of nozzles
0,4 | 0,6 | 0,8 mm
Chamber
heating up to 80°С
with convection
(optionally up to 160°С)
with convection
(optionally up to 160°С)
Printing area
1000*600*1000 mm
Heated bed
quick-change printing platform heated to 140°С (optionally up to 160°С)
User Interface
original electronics
and intuitive interface
and intuitive interface
Extruders
two high temperature
(up to 550°C)
(up to 550°C)
Diameter of nozzles
0,4 | 0,6 | 0,8 mm
Chamber
heating up to 80°С
with convection
(optionally up to 160°С)
with convection
(optionally up to 160°С)
Printing area
1000*600*1000 mm
Heated bed
quick-change printing platform heated to 140°С (optionally up to 160°С)
User Interface
original electronics
and intuitive interface
and intuitive interface
Extruders
two high temperature
(up to 550°C)
(up to 550°C)
User Interface
Original electronics and intuitive interface
Minimal training is required; by looking at the interface, you will immediately understand how to operate the printer.
User Interface
Original electronics and intuitive interface
Minimal training is required; by looking at the interface, you will immediately understand how to operate the printer.
printing chamber
Heated chamber with forced convection
Forced convection of the chamber and uniform heating allows printing large-sized parts with high interlayer adhesion.
Parts of any size do not delaminate or deform.
Parts of any size do not delaminate or deform.
printing chamber
Heated chamber with forced convection
Forced convection of the chamber and uniform heating allows printing large-sized parts with high interlayer adhesion.
Parts of any size do not delaminate or deform.
Parts of any size do not delaminate or deform.
extruders
Two high temperature extruders allow you to print with a full range of available materials
F2 printing technology provides ultra-fast heating of the extruder to the operating temperature in 3 seconds, the accuracy of maintaining the melt temperature up to 0.3°C
extruders
Two high temperature extruders allow you to print with a full range of available materials
F2 printing technology provides ultra-fast heating of the extruder to the operating temperature in 3 seconds, the accuracy of maintaining the melt temperature up to 0.3°C
Built-in air filters
Built-in air filtration system traps all particles
When heated, some plastics can evaporate harmful substances, for example, vapors of styrene derivatives, hydrocyanic acid, acetaldehyde.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
Built-in air filters
Built-in air filtration system traps all particles
When heated, some plastics can evaporate harmful substances, for example, vapors of styrene derivatives, hydrocyanic acid, acetaldehyde.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
printing bed
Quick-change print platform
heated to 140°C
heated to 140°C
The quick-change printing bed makes the printing process fast and easy.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
printing bed
Quick-change print platform
heated to 140°C
heated to 140°C
The quick-change printing bed makes the printing process fast and easy.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
By clicking the button, you're agreeing to our terms of service.
We design our printers with care and love - from sketch to final product,
so that you can be confident in every layer of printing on F2 printers.
so that you can be confident in every layer of printing on F2 printers.
