F2 Gigantry
High-perfomance pellet extruder on a portal.
- PRINTING AREA 3,5*1,8*1,5 m
- UNIQUE PRINTER
- PRINTING AREA 3,5*1,8*1,5 m
- UNIQUE PRINTER
F2 Gigantry
High-perfomance pellet extruder on a portal.
Находится в реестре Минпромторга РФ
High reliability. High productivity.
Huge printing area.
Huge printing area.
High reliability. High productivity.
Huge printing area.
Huge printing area.
F2 Gigantry
high-perfomance pellet extruder on a portal
F2 Gigantry is an open portal with an extruder, which can print 3,5*1,8*1,5 meter parts.
The technology allows printing with productivity of up to 10 kg/hour.
The technology allows printing with productivity of up to 10 kg/hour.
F2 Gigantry — unique large-sized pellet printer (printing area 3500*1800*1500 mm or another according to customer's request) that allows you to create large polymer parts quickly and cheaply, reducing costs up to 40 times compared to traditional manufacturing methods.
The portal is equipped with an F2 Pellet 8 extruder with a productivity of up to 10 kg/hour. Technology of four-zone heating of granules provides uniform material supply and high quality of the received product.
The portal is equipped with an F2 Pellet 8 extruder with a productivity of up to 10 kg/hour. Technology of four-zone heating of granules provides uniform material supply and high quality of the received product.
Granules are much cheaper than classic filament, and the resulting products are perfectly subject to post-processing - turning, milling, etc., which makes it possible to introduce additive technologies into the production chain of any manufacture.
The technology is suitable for creating disposable molds, punches, dies for laying out composites, prototyping, creating models, etc.
The technology is suitable for creating disposable molds, punches, dies for laying out composites, prototyping, creating models, etc.
F2 Pellet 8 extruder
pellet extruder
(up to 500°С),
productivity up to 10 kg/hour
(up to 500°С),
productivity up to 10 kg/hour
Enclosed heated chamber
possibility of creating a heated chamber around the portal for printing with engineering pellets
Printing area 3,5*1,8*1,5m
printing area can be adjusted according to customer's requirement
External hopper with a volume of 200 l for heating and drying pellets
pneumatic system for feeding pellets into the extruder, pellet end sensor
Nozzle diameters
3 / 5 / 8 / 10 mm
Additional options
optionally: printing at an angle of 45° and 90°
F2 Pellet 8 extruder
pellet extruder
(up to 500°С),
productivity up to 10 kg/hour
(up to 500°С),
productivity up to 10 kg/hour
Enclosed heated chamber
possibility of creating a heated chamber around the portal for printing with engineering pellets
Printing area 3,5*1,8*1,5m
printing area can be adjusted according to customer's requirement
External hopper with a volume of 200 l for heating and drying pellets
pneumatic system for feeding pellets into the extruder, pellet end sensor
Nozzle diameters
3 / 5 / 8 / 10 mm
Additional options
optionally: printing at an angle of 45° and 90°
Material economy
With hybrid technology, the coefficient of material used is only 0.8-0.9.
Strength characteristics of parts
Pellet parts have high interlayer adhesion and surpass filament parts in terms of strength characteristics. At 100% filling, the parts are not inferior to cast ones.
Implementation effect
Reduction of time and financial costs of production in various areas:
- 4-12 times faster and more profitable when creating equipment;
- 2-5 times when creating the final part.
Polymer granules
ABS / TPU / PA / ABS+СF / Keltran / PLA / PP / PETg
Polymer granules
ABS / TPU / PA / ABS+СF / Keltran / PLA / PP / PETg
